Mid-West Instrument Model 120-MA-02-OO , 0-3.5 Bar & 0-50 PSID , 1/4″ FNPT End Connections , Dual Scale
Buy with confidence direct from the official Australian Distributor for Mid-West Instrument USA.
DP Gauge manufactured by Mid-West Instrument USA.Item Code: M35120MA02OOBAR3.5PSI50
Item Description: DPGauge 2 1/2″Monel,1/4EndCons,Dual Scale
Differential Pressure Gauge
Model No: 120-MA-02-OO
DP Range: 0-3.5 Bar & 0-50 PSID Dual Scale
Dial Size: 2-1/2″ RoundStandard Model Specifications 120: 5000P.S.I.G Working pressure, Monel body & End Plugs, piston and spring, ceramic magnet, “Engineering Plastic” Gauge Case with shatter-resistant acrylic lens; +/- 5% full scale accuracy (Ascending)**
Material: M: Monel Body
Dial Size: A: 2-1/2″Round Uni-Directional Dial
Seals: 0: Buna N
Connections: 2: 1/4″ FNPT End Connections
Options: O: None
Electrical Configurations: O: None
**ASME B40.100 Grade D (Lower 25% of Scale +/-5%, Middle 50% of Scale +/-5%, Upper 25% of Scale +/-5%)
Differential Pressure Gauge
Model No: 120-MA-02-OO
DP Range: 0-3.5 Bar & 0-50 PSID Dual Scale
Dial Size: 2-1/2″ RoundStandard Model Specifications 120: 5000P.S.I.G Working pressure, Monel body & End Plugs, piston and spring, ceramic magnet, “Engineering Plastic” Gauge Case with shatter-resistant acrylic lens; +/- 5% full scale accuracy (Ascending)**
Material: M: Monel Body
Dial Size: A: 2-1/2″Round Uni-Directional Dial
Seals: 0: Buna N
Connections: 2: 1/4″ FNPT End Connections
Options: O: None
Electrical Configurations: O: None
**ASME B40.100 Grade D (Lower 25% of Scale +/-5%, Middle 50% of Scale +/-5%, Upper 25% of Scale +/-5%)
*OPTION: SPECIAL DIAL (extra cost)
